Qingdao Safval Valve Co.,Ltd
|
Cast Iron Flanged Globe Valve DIN2501 OEM
| Price: | 5.0~1000.0 USD |
| Payment Terms: | L/C |
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
globe valves
1.size:DN15-DN250
2.medium:water,steam
3.certificate:ISO9001 CE
4.standard:DIN
available medium:available medium:water ,steam
working temperature:≤200oC
flange dimensions:DIN2501
face to face dimensions:DIN3202F1
Materials:
Parts Name | Material |
Body bonnet | Gary cast iron |
Seat | iron+S.S or brass |
Wedge disc | iron+s.s or brass |
Stem | Stainless steel |
Bolt/nut | Carbon steel |
Packing | Graphite |
Stem nut | Cast brass |
Gasket | graphite |
Dimensions
DN | L | D | D1 | D2 | b | f | Z-d | Do | H | WT(kg) |
15 | 130 | 95 | 65 | 45 | 14 | 2 | 4-14 | 100 | 176 | 3.32 |
20 | 150 | 105 | 75 | 55 | 16 | 2 | 4-14 | 100 | 180 | 3.8 |
25 | 160 | 115 | 85 | 65 | 16 | 2 | 4-14 | 120 | 232 | 5.1 |
32 | 180 | 140 | 100 | 78 | 18 | 2 | 4-14 | 120 | 238 | 8 |
40 | 200 | 150 | 110 | 88 | 18 | 3 | 4-14 | 140 | 262 | 9.4 |
50 | 230 | 165 | 125 | 102 | 20 | 3 | 4-14 | 140 | 272 | 11.4 |
65 | 290 | 185 | 145 | 122 | 20 | 3 | 4-14 | 160 | 323 | 18 |
80 | 310 | 200 | 160 | 138 | 22 | 3 | 8-18 | 200 | 353 | 31 |
100 | 350 | 220 | 180 | 158 | 24 | 3 | 8-18 | 280 | 381 | 40 |
125 | 400 | 250 | 210 | 188 | 26 | 3 | 8-18 | 320 | 453 | 62 |
150 | 480 | 285 | 240 | 212 | 28 | 3 | 8-23 | 360 | 502 | 91 |
200 | 600 | 340 | 295 | 268 | 30 | 3 | 12-23 | 400 | 620 | 153 |
250 | 730 | 405 | 395 | 320 | 32 | 3 | 12-27 | 400 | 750 | 209 |
